\section{Hyperparameter Sensitivity Tables}\label{app:tables}
Full numerical results for all 32 OFAT configurations ($k$: 9 values,
$\beta$: 12 values, $\gamma$: 10 combinations, $r$: 10 values).
\begin{table}[ht]
\centering
\caption{RQ3b: Sensitivity to ENM neighborhood size $k$ (50-fold CV).
Optimal at $k$=6.}
\label{tab:rq3b_new}
\footnotesize
\begin{tabular}{lcccc}
\toprule
\textbf{$k$} & \textbf{F1} & \textbf{Recall} & \textbf{Precision} & \textbf{MCC} \\
\midrule
1 & 0.848{\tiny$\pm$0.038} & 0.816{\tiny$\pm$0.047} & 0.886{\tiny$\pm$0.056} & 0.849{\tiny$\pm$0.038} \\
2 & 0.881{\tiny$\pm$0.033} & 0.847{\tiny$\pm$0.038} & 0.921{\tiny$\pm$0.058} & 0.882{\tiny$\pm$0.033} \\
3 & 0.894{\tiny$\pm$0.030} & 0.860{\tiny$\pm$0.033} & 0.933{\tiny$\pm$0.050} & 0.895{\tiny$\pm$0.030} \\
4 & 0.905{\tiny$\pm$0.035} & 0.874{\tiny$\pm$0.034} & 0.940{\tiny$\pm$0.059} & 0.906{\tiny$\pm$0.035} \\
5 & 0.908{\tiny$\pm$0.027} & 0.877{\tiny$\pm$0.036} & 0.943{\tiny$\pm$0.043} & 0.909{\tiny$\pm$0.027} \\
6 & \textbf{0.908}{\tiny$\pm$0.030} & \textbf{0.881}{\tiny$\pm$0.037} & 0.940{\tiny$\pm$0.051} & \textbf{0.909}{\tiny$\pm$0.030} \\
7 & 0.907{\tiny$\pm$0.035} & 0.879{\tiny$\pm$0.040} & 0.939{\tiny$\pm$0.055} & 0.908{\tiny$\pm$0.034} \\
8 & 0.906{\tiny$\pm$0.036} & 0.874{\tiny$\pm$0.042} & 0.944{\tiny$\pm$0.058} & 0.907{\tiny$\pm$0.036} \\
9 & 0.900{\tiny$\pm$0.036} & 0.874{\tiny$\pm$0.040} & 0.932{\tiny$\pm$0.058} & 0.901{\tiny$\pm$0.035} \\
\bottomrule
\end{tabular}
\end{table}
\begin{table}[ht]
\centering
\caption{Sensitivity to grafting temperature $\beta$ ($k$=7, 50-fold CV).}
\label{tab:rq3b_beta}
\footnotesize
\begin{tabular}{lcccc}
\toprule
\textbf{$\beta$} & \textbf{F1} & \textbf{Recall} & \textbf{Precision} & \textbf{MCC} \\
\midrule
0.5 & 0.895{\tiny$\pm$0.034} & 0.854{\tiny$\pm$0.049} & 0.942{\tiny$\pm$0.038} & 0.896{\tiny$\pm$0.034} \\
1.0 & 0.905{\tiny$\pm$0.035} & 0.871{\tiny$\pm$0.045} & 0.944{\tiny$\pm$0.043} & 0.906{\tiny$\pm$0.035} \\
1.5 & 0.908{\tiny$\pm$0.030} & 0.873{\tiny$\pm$0.042} & 0.948{\tiny$\pm$0.039} & 0.909{\tiny$\pm$0.030} \\
2.0 & 0.911{\tiny$\pm$0.030} & 0.878{\tiny$\pm$0.041} & 0.948{\tiny$\pm$0.042} & 0.912{\tiny$\pm$0.030} \\
\textbf{2.5} & \textbf{0.911}{\tiny$\pm$0.032} & \textbf{0.878}{\tiny$\pm$0.039} & 0.949{\tiny$\pm$0.044} & \textbf{0.912}{\tiny$\pm$0.032} \\
3.0 & 0.907{\tiny$\pm$0.035} & 0.879{\tiny$\pm$0.040} & 0.939{\tiny$\pm$0.055} & 0.908{\tiny$\pm$0.034} \\
3.5 & 0.906{\tiny$\pm$0.037} & 0.878{\tiny$\pm$0.039} & 0.938{\tiny$\pm$0.058} & 0.907{\tiny$\pm$0.036} \\
4.0 & 0.908{\tiny$\pm$0.034} & 0.879{\tiny$\pm$0.037} & 0.941{\tiny$\pm$0.056} & 0.908{\tiny$\pm$0.034} \\
4.5 & 0.906{\tiny$\pm$0.034} & 0.876{\tiny$\pm$0.039} & 0.940{\tiny$\pm$0.054} & 0.907{\tiny$\pm$0.034} \\
5.0 & 0.906{\tiny$\pm$0.033} & 0.878{\tiny$\pm$0.037} & 0.939{\tiny$\pm$0.056} & 0.907{\tiny$\pm$0.033} \\
5.5 & 0.905{\tiny$\pm$0.035} & 0.877{\tiny$\pm$0.041} & 0.938{\tiny$\pm$0.055} & 0.906{\tiny$\pm$0.035} \\
6.0 & 0.905{\tiny$\pm$0.036} & 0.876{\tiny$\pm$0.040} & 0.940{\tiny$\pm$0.060} & 0.906{\tiny$\pm$0.036} \\
\bottomrule
\end{tabular}
\end{table}
\begin{table}[ht]
\centering
\caption{Sensitivity to elastic range $\gamma$ ($k$=7, $\beta$=3.0, 50-fold CV).}
\label{tab:rq3b_gamma}
\footnotesize
\begin{tabular}{lcccc}
\toprule
\textbf{$\gamma$} & \textbf{F1} & \textbf{Recall} & \textbf{Precision} & \textbf{MCC} \\
\midrule
{[0.0, 0.5]} & 0.833{\tiny$\pm$0.057} & 0.769{\tiny$\pm$0.047} & 0.914{\tiny$\pm$0.094} & 0.837{\tiny$\pm$0.057} \\
{[0.0, 1.0]} & 0.865{\tiny$\pm$0.043} & 0.819{\tiny$\pm$0.049} & 0.920{\tiny$\pm$0.061} & 0.867{\tiny$\pm$0.043} \\
{[0.5, 1.0]} & 0.887{\tiny$\pm$0.032} & 0.837{\tiny$\pm$0.047} & 0.947{\tiny$\pm$0.038} & 0.889{\tiny$\pm$0.032} \\
{[0.5, 1.5]} & 0.897{\tiny$\pm$0.039} & 0.882{\tiny$\pm$0.040} & 0.915{\tiny$\pm$0.063} & 0.898{\tiny$\pm$0.039} \\
{[0.5, 2.0]} & 0.899{\tiny$\pm$0.045} & 0.888{\tiny$\pm$0.040} & 0.915{\tiny$\pm$0.076} & 0.900{\tiny$\pm$0.044} \\
{[0.8, 1.2]} & 0.906{\tiny$\pm$0.035} & 0.874{\tiny$\pm$0.044} & 0.942{\tiny$\pm$0.044} & 0.907{\tiny$\pm$0.035} \\
{[0.8, 1.5]} & 0.907{\tiny$\pm$0.035} & 0.879{\tiny$\pm$0.040} & 0.939{\tiny$\pm$0.055} & 0.908{\tiny$\pm$0.034} \\
{[0.8, 2.0]} & \textbf{0.909}{\tiny$\pm$0.035} & \textbf{0.880}{\tiny$\pm$0.042} & 0.943{\tiny$\pm$0.055} & \textbf{0.910}{\tiny$\pm$0.035} \\
{[1.0, 1.5]} & 0.906{\tiny$\pm$0.033} & 0.860{\tiny$\pm$0.044} & 0.960{\tiny$\pm$0.043} & 0.908{\tiny$\pm$0.032} \\
{[1.0, 2.0]} & 0.905{\tiny$\pm$0.037} & 0.862{\tiny$\pm$0.045} & 0.955{\tiny$\pm$0.057} & 0.906{\tiny$\pm$0.037} \\
\bottomrule
\end{tabular}
\end{table}
\begin{table}[ht]
\centering
\caption{Sensitivity to target ratio $r$ ($k$=7, $\beta$=3.0, 50-fold CV).}
\label{tab:rq3b_r}
\footnotesize
\begin{tabular}{lcccc}
\toprule
\textbf{$r$} & \textbf{F1} & \textbf{Recall} & \textbf{Precision} & \textbf{MCC} \\
\midrule
0.1 & 0.889{\tiny$\pm$0.031} & 0.826{\tiny$\pm$0.046} & 0.965{\tiny$\pm$0.044} & 0.892{\tiny$\pm$0.030} \\
0.2 & 0.900{\tiny$\pm$0.032} & 0.850{\tiny$\pm$0.044} & 0.958{\tiny$\pm$0.045} & 0.902{\tiny$\pm$0.031} \\
0.3 & 0.904{\tiny$\pm$0.029} & 0.861{\tiny$\pm$0.041} & 0.954{\tiny$\pm$0.043} & 0.905{\tiny$\pm$0.029} \\
0.4 & 0.907{\tiny$\pm$0.033} & 0.869{\tiny$\pm$0.043} & 0.951{\tiny$\pm$0.048} & 0.908{\tiny$\pm$0.032} \\
\textbf{0.5} & \textbf{0.909}{\tiny$\pm$0.031} & \textbf{0.874}{\tiny$\pm$0.039} & 0.950{\tiny$\pm$0.046} & \textbf{0.911}{\tiny$\pm$0.031} \\
0.6 & 0.907{\tiny$\pm$0.032} & 0.873{\tiny$\pm$0.041} & 0.946{\tiny$\pm$0.049} & 0.908{\tiny$\pm$0.032} \\
0.7 & 0.908{\tiny$\pm$0.031} & 0.877{\tiny$\pm$0.040} & 0.945{\tiny$\pm$0.048} & 0.909{\tiny$\pm$0.031} \\
0.8 & 0.907{\tiny$\pm$0.035} & 0.879{\tiny$\pm$0.040} & 0.939{\tiny$\pm$0.055} & 0.908{\tiny$\pm$0.034} \\
0.9 & 0.908{\tiny$\pm$0.035} & 0.877{\tiny$\pm$0.041} & 0.945{\tiny$\pm$0.052} & 0.909{\tiny$\pm$0.035} \\
1.0 & 0.909{\tiny$\pm$0.033} & 0.881{\tiny$\pm$0.040} & 0.942{\tiny$\pm$0.050} & 0.910{\tiny$\pm$0.032} \\
\bottomrule
\end{tabular}
\end{table}
\section{Factorial Interaction Results}\label{app:factorial}
Table~\ref{tab:factorial} reports the full $2^4$ factorial
experiment (16 configurations, 50-fold CV each). The maximum
two-way interaction magnitude is $0.57\%$ ($\beta\times\gamma$),
confirming the absence of significant parameter coupling.
\begin{table}[ht]
\centering
\caption{$2^4$ Factorial interaction verification (EUSES, 50-fold
CV, $n=50$ per config). Factor levels: $k\in\{5,8\}$,
$\beta\in\{2.0,4.0\}$, $\gamma\in\{(0.8,1.2),(0.8,2.0)\}$,
$r\in\{0.4,1.0\}$.}
\label{tab:factorial}
\footnotesize
\begin{tabular}{lcccc}
\toprule
\textbf{Config} & \textbf{F1} & \textbf{Recall} & \textbf{Precision} & \textbf{MCC} \\
\midrule
$k$=5 $\beta$=2.0 $\gamma$=(0.8,1.2) $r$=0.4 & 0.901$\pm$0.032 & 0.855$\pm$0.043 & 0.954$\pm$0.031 & 0.902$\pm$0.032 \\
$k$=5 $\beta$=2.0 $\gamma$=(0.8,1.2) $r$=1.0 & 0.906$\pm$0.032 & 0.864$\pm$0.044 & 0.953$\pm$0.031 & 0.907$\pm$0.031 \\
$k$=5 $\beta$=2.0 $\gamma$=(0.8,2.0) $r$=0.4 & 0.909$\pm$0.036 & 0.866$\pm$0.048 & 0.958$\pm$0.035 & 0.910$\pm$0.036 \\
$k$=5 $\beta$=2.0 $\gamma$=(0.8,2.0) $r$=1.0 & 0.908$\pm$0.036 & 0.874$\pm$0.046 & 0.946$\pm$0.041 & 0.909$\pm$0.036 \\
$k$=5 $\beta$=4.0 $\gamma$=(0.8,1.2) $r$=0.4 & 0.902$\pm$0.038 & 0.862$\pm$0.047 & 0.947$\pm$0.038 & 0.903$\pm$0.037 \\
$k$=5 $\beta$=4.0 $\gamma$=(0.8,1.2) $r$=1.0 & 0.905$\pm$0.037 & 0.871$\pm$0.046 & 0.943$\pm$0.039 & 0.906$\pm$0.037 \\
$k$=5 $\beta$=4.0 $\gamma$=(0.8,2.0) $r$=0.4 & 0.904$\pm$0.040 & 0.863$\pm$0.047 & 0.951$\pm$0.045 & 0.905$\pm$0.040 \\
$k$=5 $\beta$=4.0 $\gamma$=(0.8,2.0) $r$=1.0 & 0.903$\pm$0.042 & 0.869$\pm$0.047 & 0.941$\pm$0.052 & 0.904$\pm$0.042 \\
$k$=8 $\beta$=2.0 $\gamma$=(0.8,1.2) $r$=0.4 & 0.895$\pm$0.038 & 0.850$\pm$0.044 & 0.947$\pm$0.040 & 0.897$\pm$0.038 \\
$k$=8 $\beta$=2.0 $\gamma$=(0.8,1.2) $r$=1.0 & 0.896$\pm$0.032 & 0.856$\pm$0.039 & 0.940$\pm$0.040 & 0.897$\pm$0.032 \\
$k$=8 $\beta$=2.0 $\gamma$=(0.8,2.0) $r$=0.4 & 0.905$\pm$0.030 & 0.862$\pm$0.040 & 0.953$\pm$0.035 & 0.906$\pm$0.030 \\
$k$=8 $\beta$=2.0 $\gamma$=(0.8,2.0) $r$=1.0 & 0.906$\pm$0.031 & 0.869$\pm$0.038 & 0.948$\pm$0.042 & 0.907$\pm$0.030 \\
$k$=8 $\beta$=4.0 $\gamma$=(0.8,1.2) $r$=0.4 & 0.902$\pm$0.036 & 0.862$\pm$0.041 & 0.948$\pm$0.045 & 0.904$\pm$0.036 \\
$k$=8 $\beta$=4.0 $\gamma$=(0.8,1.2) $r$=1.0 & 0.899$\pm$0.030 & 0.867$\pm$0.039 & 0.934$\pm$0.042 & 0.899$\pm$0.030 \\
$k$=8 $\beta$=4.0 $\gamma$=(0.8,2.0) $r$=0.4 & 0.903$\pm$0.030 & 0.863$\pm$0.038 & 0.948$\pm$0.044 & 0.904$\pm$0.030 \\
$k$=8 $\beta$=4.0 $\gamma$=(0.8,2.0) $r$=1.0 & 0.905$\pm$0.032 & 0.874$\pm$0.038 & 0.941$\pm$0.045 & 0.906$\pm$0.032 \\
\bottomrule
\end{tabular}
\end{table}
\section{RQ2 Detailed Results}\label{app:rq2}
\begin{table}[ht]
\centering
\caption{RQ2 CNFS threshold sweep (EUSES fault cells, 50-fold CV).}
\label{tab:rq2_sweep}
\footnotesize
\begin{tabular}{lrrr}
\toprule
\textbf{Threshold $\tau$} & \textbf{Coverage (\%)} & \textbf{SDA F1} & \textbf{Best Baseline F1} \\
\midrule
0.0 & 100.0\% & 0.938 & 0.902 \\
0.1 & 99.6\% & 0.939 & 0.902 \\
0.2 & 99.6\% & 0.939 & 0.902 \\
0.3 & 96.4\% & 0.940 & 0.903 \\
\textbf{0.4} & \textbf{86.8\%} & \textbf{0.941} & \textbf{0.903} \\
0.5 & 71.8\% & 0.941 & 0.900 \\
0.6 & 49.0\% & 0.944 & 0.899 \\
0.7 & 28.5\% & 0.946 & 0.910 \\
0.8 & 7.0\% & 0.957 & 0.921 \\
0.9 & 3.2\% & 0.977 & 0.952 \\
\bottomrule
\end{tabular}
\end{table}
\begin{table}[ht]
\centering
\caption{Marginal contribution decomposition by CNFS bin
($n=688$ fault cells). F1 equals recall because the detection
matrix contains only fault cells. SDA-exclusive TP: cells detected
by SDA but missed by all three baselines.}
\label{tab:rq2_marginal}
\footnotesize
\begin{tabular}{lrrrrr}
\toprule
\textbf{CNFS bin} & \textbf{Cells} & \textbf{SDA F1} & \textbf{Best base F1} & \textbf{$\Delta$F1} & \textbf{SDA-excl TP} \\
\midrule
{[0.1,0.2)} & 3 & 1.000 & 1.000 & 0.000 & 0 \\
{[0.2,0.3)} & 22 & 0.955 & 0.864 & +0.091 & 0 \\
{[0.3,0.4)} & 66 & 0.894 & 0.833 & +0.061 & 4 \\
{[0.4,0.5)} & 103 & 0.816 & 0.757 & +0.058 & 5 \\
{[0.5,0.6)} & 157 & 0.898 & 0.822 & +0.076 & 7 \\
{[0.6,0.7)} & 141 & 0.894 & 0.830 & +0.064 & 9 \\
{[0.7,0.8)} & 148 & 0.892 & 0.824 & +0.068 & 4 \\
{[0.8,0.9)} & 26 & 0.885 & 0.923 & $-0.038$ & 0 \\
{[0.9,1.0]} & 22 & 0.864 & 0.818 & +0.045 & 2 \\
\midrule
All & 688 & 0.884 & 0.821 & +0.062 & 31 \\
\bottomrule
\end{tabular}
\end{table}
|
